TD-4550DNWB - Professional Wireless Desktop Label Printer With Bluetooth

Print high-quality, continuous labels using media up to 118mm wide. With built-in network, wireless and Bluetooth connectivity.

  • Error: Generic Text label 'Warranties' not set for language 'is-IS' (Site: 'MAIN-Nordics').

User-friendly backlit LCD screen

Professional quality up to 300dpi print resolution

Fast print speeds up to 152mm/sec.

Product Details

TD4550DNWB_main

Print width up to 108.4mm

Easy set-up with automatic media configuration

Ready to integrate with iOS and Android apps

Key Features

  • User-friendly backlit LCD screen
  • Professional quality up to 300dpi print resolution
  • Fast print speeds up to 152mm/sec.

  • Print width up to 108.4mm
  • Easy set-up with automatic media configuration
  • Ready to integrate with iOS and Android apps

About Product:

With an intuitive LCD screen, the TD-4550DNWB is a user-friendly desktop label printer. The professional quality resolution, makes this label maker ideal for printing 2D barcodes. Barcodes are easily scanned and quickly processed.

The Bluetooth connectivity allows for setup and configuration with a smartphone or tablet using the Mobile Deploy App. Whilst wireless connectivity removes the need of cables for the network.

Using direct thermal print technology prevents sheet label wastage. Print only the exact number of labels that you need.

With automatic media calibration, the length and width of your media is calculated. You simply insert your new roll of labels and follow the screen prompts.

Customise to your specific requirements with a range of accessories including peeler and cutter. Making the TD-4550DNWB a truly versatile label maker.

Compatible with

  • Wifi / Wireless compatible
  • Wireless network connectivity
  • Hi-Speed USB 2.0 connection interface

Supplies & Accessories

Show more +
Show Less -

Specifications

General

Flash RAM 64 MB
Housing colour White and grey
RAM 256 MB
Technology Direct thermal
Maximum label width (mm) 118
Control panel 7 button, 3 LED
LED Power, Data, Status, Error
Real-time clock Yes

Connectivity

Bluetooth Version 4.2
Bluetooth profiles SPP, OPP, HCRP, Bluetooth Clasic, GATT (Bluetooth Low Energy)
Serial RS-232C Serial (DB9 male)
USB interface USB Ver. 2.0 (Full Speed) Type B
Wired network interface 10/100Base-TX
Wirelesss network interface 802.11a/b/g/n
AirPrint Yes
MFi Yes

Dimensions & weights

Dimensions 108mm (W) x 155mm (D) x 224mm (H)
Weight 2.08 kg

In the box

AC adaptor power cord Yes
USB cable Yes
Warranty card Yes
AC adaptor Yes
Software Available to download from support.brother.com
Quick setup guide Yes

Operating systems & software

Linux Linux
Windows Server 2008, Server 2008R2, Server 2012, Server 2012R2, Server 2016, Windows 7, Windows 8, Windows 8.1, Windows 10
Android Android 4.0.3 or later
IOS iOS® 8 or later

Printing

Bitmap fonts Helsinki, Letter Gothic Bold, San Diego, Brougham, Brussels, Gothic
Copies 1-9999 (ESC/P P-touch Template)
Label detection sensor Yes
Maximum label width 118 mm
Maximum print length 3000 mm
Mirror printing Yes
Resolution (dpi) 300 x 300
Sequential numbering 1 - 9999 / A - Z / a - z
Standard print speed 152.4 mm per second
Supported commands P-touch Template, Raster, ESC/P, ZPL II emulation, CPCL emulation
Maximum print width 108.4 mm

P-touch Editor label design software

Database file compatability csv, Microsoft Access, Microsoft Excel
Date and time stamp Date and time
Label length settings 25 mm (minimum)
Languages English / Danish / Dutch / French / German / Italian / Norwegian / Portuguese / Spanish / Swedish / Finnish / Czech / Polish / Hugarian / Simplified Chinese / Russian / Turkish / Japanese
Microsoft Office add-in (highlight->click->print) Excel, Outlook, Word
Screen capture Yes
Typestyles Bold, Horizontal lines, Invert, Italic, Normal, Outside frame, Shadow, Shadow light, Surround

Solutions

SDK (Software Development Kit) Yes

Supplies and accessories

Rolls RD rolls (die-cut and continuous)
Optional accessories Cutter, Peeler, Platen roller, Thermal print head

Warranty

Warranty 2-Year Warranty
Show more +
Show Less -

Support & documents

woman sat at a desk on a laptop

Downloads & Drivers

Download and install the latest drivers and software for your Brother products.

View Downloads
man and a woman sat a desk on a laptop

FAQs

Find the answers to our most frequently asked questions and troubleshooting here.

View FAQs
man sat on a sofa working on a tablet

Manuals & Guides

Download the latest manuals and user guides for your Brother products

View Manuals

More about this product...

LCD display showing media configuration icon

Intuitive LCD

The integrated LCD screen makes setting up and configuration a simple task. The backlit screen with user-friendly buttons helps you to quickly get up and running.

Brother TD-4550DNWB desktop label printer on wooden desk person holding label from label printer

Crop function

Reduce the amount of paper waste by adopting this easy-to-use feature. Whether it is an A4 sheet of product or shipping labels.

The barcode information contained within the document is automatically scanned and processed. Individual labels are then printed from your TD-4550DNWB desktop label printer.

TD4550_Network

Flexible connectivity

Use the TD-4550DNWB where you need it, without the need of trailing wires. With built-in Wi-Fi and Bluetooth connectivity, the TD-4550DNWB is truly versatile. Many users can also share the label printer via the integrated network port.

Brother TD-4550DNWB desktop label printer printing food label next to sandwiches

Remotely update

Enabling IT administrators to remotely update and configure many Brother label printers. Updates are easily uploaded to an online location and the URL's shared with users to install the latest configuration via the Mobile Deploy App.

Hand inserting USB cable in to back of Brother TD-4550DNWB desktop label printer

Integrated USB host

A USB host is built-in as standard. Enabling a barcode reader or weighing scales to be connected. Barcodes are read to create print information. Using pre-defined templates, your information is printed on to labels.

Doctor printing medical label using Brother TD-4550DNWB desktop label printer

Seamless integration

For easy integration, many printer command languages are supported. Including ZPL II emulation, Raster, CPCL emulation enabling integration into legacy systems.

Brother TD-4550DNWB desktop label printer on wooden desk person holding label from label printer

Print from Windows PC

Create customer labels using Brother P-touch Editor. You can easily add your company logo or select from hundreds of built-in images, symbols, barcodes and frames. Also, link to excel data to batch print labels.

printing

Software support

Brother provides the tools for developers to integrate their printing applications. Printer drivers are available for Windows Operating Systems. Software Development Kits are available to embed label printing into existing software programs. Software Development Kits available from: www.brother.eu/developer
